Lux 1000 Thermostat Instructions

A large percentage of a household's budget is consumed by heating and cooling costs. Using a programmable thermostat reduces energy usage which equals lower energy bills. The Lux 1000 Thermostat is simple to program. Maximum control over energy usage can be obtained through programming up to 4 different settings for weekdays, Saturday and Sunday.

Setting the Time and Day

Step 1

Press "Day/Time" once to begin programming the day.

Step 2

Press "Ahead" or "Back" to adjust the day.

Step 3

Press "Day/Time" again to begin programming the time.

Step 4

Press "Ahead" or "Back to change the time.

Step 5

Press "Return" when settings are finished.

Programming Temperature Settings

Step 1

Press "W-Day" to begin programming.

Step 2

Press "Ahead" or "Back" to select the time for this programmed setting to begin.

Step 3

Press "Temp Up" or "Temp Dn" to adjust the temperature setting.

Step 4

Press "Weekday Again" to shift to the next programming period. Set the time and temperature for all four periods.

Step 5

Press "W-Day" to shift to Saturday programming. Set the time and temperature for all four periods on Saturday.

Step 6

Press "W-Day" to shift to Sunday programming. Set the time and temperature for all four periods on Sunday.

Step 7

Press "Return" when all settings are complete.
