Industrial Processes to Make Ceramic Cups

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.
Ceramic cups are made using the slip casting technique.

Ceramic cups are ideal for coffee or tea and can be simple or customized. Ceramic mugs are made using a potter's wheel, the hand-building technique or through slip casting in molds. Hand-building and making mugs on a potter's wheel are time-consuming and not as practical as slip casting, because the mugs that result have different sizes and even shapes. The industrial process used to make ceramic cups is through slip casting in molds.

Advertisement

The Prototype

The first stage in the industrial process of making ceramic cups is to create a prototype in plaster or plastic. Plastic is more recommended, because it won't be destroyed when casting the molds. Plaster molds are destroyed while casting several sets of molds. The prototype may be hand-built or carved into a block of material. The prototype contains all the details and looks like the final product.

Advertisement

Video of the Day

The Molds

Plaster molds are necessary to be able to replicate the ceramic cups. Several molds are prepared so that multiple cups can be cast at the same time and increase productivity. The molds are cast after the prototype and contain several parts, typically two halves for the body of the cup and additional two halves for the handles.

Advertisement

The Slip Casting

Ceramic cups are manufactured using porcelain, earthenware or stoneware. The material is diluted using water until the clay becomes liquid. The clay is cast into the plaster molds. Filling a mold with clay takes under one minute. The clay is left to harden and the plaster mold absorbs the moisture from the material. When the clay hardens, the molds are removed.

Advertisement

The Firing of Cups

The firing of the ceramic cups is scheduled after the clay is completely dry. Hundreds of cups can be fired in a large kiln, which contains several shelves. The firing temperature depends on the clay used to make the mugs: porcelain requires temperatures up to 2,600 degrees F, while earthenware requires temperatures below 2,100 degrees. The firing time is between two and 12 hours, depending on the type and size of the kiln. Immediately after the firing is finished, the cups are extremely hot, so they can only be removed a few hours after that using thick gloves.

Advertisement

The Glazing and Second Firing

The final stage in the making of ceramic mugs is the glazing, which is performed when the cups are no longer warm. Glazes add color and a glossy texture to the cups; the cups may have an even color or patterns and drawings. After applying the glazes, the cups will be fired again. The firing temperatures depend on the types of glazes and the initial material used for making the mugs.
