Rust-Oleum Epoxy Shield Instructions

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

Things You'll Need

  • Garbage bags

  • Duct tape

  • Vacuum

  • Broom

  • Mop

  • Trisodiumphosphate (TSP)

  • Bucket

  • Bleach

  • Concrete etcher

  • Paint brush

  • High-quality paint roller

Epoxy paint can bring new life to an old garage floor.

Rust-Oleum Epoxy Shield Garage Floor Coating is designed to give your concrete garage floor a sleek finish and resistance against gasoline, antifreeze, motor oil, salt and tire marks. Rust-Oleum Epoxy Shield comes in a kit that includes an instructional video, paint, decorative chips and a stir stick. With the instructions and a few extra tools, the Epoxy Shield goes on easily. But to maintain its finish for years, it must be laid on a well-prepared garage floor.


Step 1

Place the Epoxy Shield in the garage and leave it there for 48 hours before you apply it. This acclimation period will allow the Epoxy Shield to reach the temperature of the surrounding room -- the optimal temperature for application.

Video of the Day

Step 2

Test the concrete for moisture penetration from the subfloor. Place garbage bags over a 2 square foot section of the floor. Then duct tape the edges of the bags down (and any seams). Leave the bags in place for 24 hours. Lift the plastic and check for moisture. If the concrete appears darker or there are water droplets on the underside of the bags, the floor cannot be sealed. The water penetrating through the concrete will lift the Epoxy Shield. A vapor barrier must be placed underneath the floor to prevent moisture seepage. Epoxy Shield cannot be applied to sealed floors.


Step 3

Clean with the floor vacuum or sweep to remove surface debris. Mop the floor with trisodiumphosphate (TSP) solution diluted with water according to the manufacturer's instructions. However, if there is mildew damage on the floor, you must mop with bleach and water in a 10 percent solution. Follow with a clean water mop to remove the solution from the floor.


Step 4

Etch the surface of the floor with a commercial concrete etcher (Rust-Oleum advises against using muriatic acid) mixed with water and applied according to the manufacturer's instructions. Never place concentrated etcher directly on the floor. Once the etch is applied and rinsed, wipe the dried floor with a finger. If there is any dust on your fingers, rinse and scrub the floor again. Once no dust is transferred to your fingers, proceed to the next step.


Step 5

Mix the Epoxy Shield. Pour Part A into Part B and stir thoroughly with the paint mixer for three full minutes. Make sure to scrape the sides and bottom of the can as you stir. Let the mixture stand for 30 minutes. Then mix it again. If you have also purchased Rust-Oleum's anti-slip additive, add it to the mixed paint and then mix once more.


Step 6

Paint the Epoxy Shield around the edges of the garage floor with a paint brush. These areas are tougher to reach with a paint roller.

Step 7

Apply the Epoxy Shield to the rest of the floor, one 4 square foot section at a time. Toss the decorative paint chips onto the wet paint after you finish each section.


Step 8

Allow the floor to dry for four hours with the garage door open. After four hours, the floor is safe to walk on. After 12 hours it is ready for regular use.


The outdoor temperature must be above 60 degrees Fahrenheit and under 85 degrees Fahrenheit when you apply the Epoxy Shield and remain above 60 degrees overnight. The humidity must be under 80 percent. Epoxy Shield cannot be applied to sealed concrete. To test and see if your concrete is sealed, dribble a little water onto the surface. If it beads, the concrete is sealed. For the best results, strip any paint layer already on the concrete. If that is impractical, scrape and sand any chipping paint on the paint layer. Repair any damage to the floor before applying Epoxy Shield. Epoxy Shield is only listed for use in covered garages. Freshly-poured concrete must cure for at least 28 days before it can be coated with Epoxy Shield.
