How to Etch on Acrylic

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

Things You'll Need

  • Plexiglass

  • Vinyl

  • Transfer paper

  • X-acto knife

  • Etching cream

  • Sandblaster

  • Design

  • Tape

  • Pen

  • Etcher or rotary tool

Etching can be done in a number of ways.

Etching is an effective way to customize a piece of acrylic or glass. Some methods of etching include: etching cream, sandblasting and using a rotary tool. A rotary tool, or etcher, requires a steady hand but will help you achieve fine lines, while the other methods allow you to etch a surface fairly quickly once you have a stencil that you are willing to work with. It may take a few tries to achieve optimum results, but you will be rewarded with a custom acrylic surface and the knowledge of etching techniques that can be translated to etch glass as well.

Advertisement

Etching with a Cream or Abrasive

Step 1

Place a piece of vinyl over the area that will be etched. Use adhesive-backed vinyl or use an adhesive that will allow you to peel the stencil away once you are finished.

Video of the Day

Step 2

Transfer your design to the vinyl by tracing the pattern over transfer paper.

Advertisement

Step 3

Follow the lines you transferred onto the vinyl with an X-acto knife and then peel away the pieces from where you are etching.

Step 4

Apply etching cream over the stencil or use a sandblaster to begin your etching. Leave the etching cream on for as long as the manufacturer recommends.

Advertisement

Step 5

Remove the stencil and wash the surface with water and a mild soap. If you used etching cream, follow the manufacturers instructions for removal.

Etching with a Rotary Tool or Etcher

Step 1

Choose a design to etch to the plexiglass.

Advertisement

Step 2

Tape the design to the back side of the glass. You could also trace the design to the glass with a permanent marker.

Step 3

Turn on the etcher or rotary tool at a low rpm and trace along the design to etch into the glass.

Tip

If you do not have access to a sandblaster, use fine-grit sandpaper to etch into the glass.
