How to Attach Wood to a Concrete Block

Save
Attaching wood to concrete is surprisingly easy.
Attaching wood to concrete is surprisingly easy. (Image: Alongside harbor dock image by Pezography from Fotolia.com)

Attaching a wooden board to concrete is a project that many amateur builders dread. In reality, however, the project is surprisingly simple. It doesn't require concrete anchor bolts or other or any other finicky equipment; according to AskTheBuilder.com, you can complete the job with only a masonry drill, some nails and a hammer. The connection is as strong as it is easy. Nothing short of a crowbar will pry the nails from the concrete block.

Things You'll Need

  • Wood
  • Concrete
  • Clamp
  • Tape
  • Masonry drill
  • 16-inch-long, 1/4-inch masonry bit
  • 16-penny sinker nails
  • 20-oz. hammer

Place the wood on the concrete so that it is lined up exactly how you like it. Fasten it with a clamp or some tape, or hold it in place with your hand.

Drill a hole into the wooden board near the end with a masonry drill. Continue drilling straight down through the board and into the concrete. As you drill, pull the bit out every few seconds with the drill still spinning to empty out the wood and concrete dust.

Insert two nails side-by-side into the opening with their ends even.

Drive the nails into the wood with firm, straight strokes. Continue to drive them down until they are sunk all the way into the board.

Drill a second hole through the board and concrete block 16 and 24 inches from the first hole and drive nails in as above. Continue to drill holes every 16 inches to 24 inches until you have anchored the entire board.

Remove the tape or clamp if you used one.
