How Do I Replace a Cub Cadet GT 1554 Drive Belt?

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.
Replacing the drive belt on your Cub Cadet will have it working like new again.

Even with dutiful yearly maintenance, the working parts of your GT Cub Cadet will ultimately exhibit the normal indicators of wear and tear. The drive belt on your riding mower is particularly vulnerable to becoming loose and brittle over the years, finally snapping. When this comes to pass, your lawn tractor will no longer work as intended, as the drive belts power the rotation of the mowing blades. Replacing the broken belt on your Cub Cadet is a speedy and straightforward procedure that is the same for all GT series Cub Cadets.

Advertisement

Step 1

Place your Cub Cadet mower on an even, flat surface. Remove the ignition key and set the parking brake. Notice the belt replacement guide situated on the left floorboard to obtain a valuable outline of how the belt is attached.

Video of the Day

Step 2

Grip the attachment lever positioned adjacent to the steering wheel, on the right. Push the top button to release it. Pull the lever back until you unlock the mower deck. Pull the entire mower deck free from the Cub Cadet. Grip the lever again and push it all the way forward until the motor housing reaches its lowest level.

Advertisement

Step 3

Slide underneath the lawn tractor and manually pull the non-working drive belt off the engine pulley. Seize the retainer pin holding both clutch retainer springs to the pulley bolt and pull it out. The retainer springs are situated in the dead center of the mowing deck. Take off both retainer springs to pull off the belt collar and unfasten the main housing bracket.

Advertisement

Step 4

Pull the broken belt off the mower's stationary idler pulley, then yank the final remaining part of the drive belt off the clutch idler pulley. Both idler pulleys can be found immediately adjacent to the engine pulley.

Step 5

Fasten the replacement Cub Cadet drive belt tightly to the grooves on the clutch idler pulley. Manually rotate the clutch idler pulley one-half turn. Affix the remaining section of the replacement belt to the stationary idler pulley until the belt is taut. Realign the portions of the mower housing and lock the retainer springs. Reinsert the metal pin to secure the retainer. Align the mower body housing and lock it back into the front of the Cub Cadet.

Advertisement

Step 6

Grasp the clutch lever once more and pull it back to set the deck to your desired height. Start your Cub Cadet GT mower and check for correct operation.
