How to Use a Chuck Tool Drift Key

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

The chuck of a drill press wears over time due to drill bits slipping and the pressure required to drill through tough metals, such as stainless steel. When a chuck is worn, a secured drill bit will wobble and wander across the surface of the material you are drilling. You need a special tool–a drift key–to remove the chuck from a drill press.

Advertisement

Image Credit: drill press image by Nancy Ottenweller from <a href='http://www.fotolia.com'>Fotolia.com</a>

Video of the Day

Things You'll Need

  • Drill Press

  • Safety Glasses

  • Drift Key

  • Work Gloves

  • Hammer

Step 1

Put on your safety glasses and work gloves.

Video of the Day

Step 2

Turn the chuck of the drill press with your hands until you see the slot of the spindle arm align with the quill slot located on the drill press housing.

Step 3

Insert the drift key into the quill slot with the tapered side of the drift key facing toward the chuck of the drill press.

Advertisement

Step 4

Tap on the back of the drift key with the hammer to drive the drift key into the spindle slot.

Step 5

Hold the chuck with one hand and hit the back of the drift key hard to free the spindle from the drill press. This may require a few hits.

Advertisement

Step 6

Lower the hand holding the chuck to allow the spindle to fall free from the drill press.

Step 7

Pull the drift key from the quill slot and make sure you don't lose it. The drift key is shaped to fit your specific drill press model.
