How to Replace a Tecumseh Cylinder Head Gasket

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

Things You'll Need

  • Socket set and socket ratchet

  • Head gasket

  • Foot-pound Torque wrench

When your Tecumseh engine will not start, but it has spark, gas and a clean air filter, then you will need to check the compression. A compression test that shows air pressure under 10 psi (pounds per square inch) indicates that the piston rings are worn out, or the head gasket is worn out. Replacing the cylinder head gasket only takes a few tools and can be done in your own garage.

Advertisement

Step 1

Pull the spark plug cap off the spark plug on the front of the Tecumseh engine.

Video of the Day

Step 2

Unscrew the eight bolts holding the cylinder head on the front of the Tecumseh engine, using the appropriate socket, usually 9/16 inch.

Advertisement

Step 3

Pull the cylinder head off to expose the top of the piston and the head gasket stuck to the back of the cylinder head.

Step 4

Peel off the head gasket and place the new one on the cylinder head.

Advertisement

Step 5

Place the cylinder head back on the engine block with the new head gasket in place.

Step 6

Finger-tighten the bolts through the cylinder head and into the engine block.

Step 7

Fit the socket you used to unscrew the cylinder head bolts on the foot-pound torque wrench.

Advertisement

Step 8

Finish tightening the cylinder head bolts with the foot-pound torque wrench. Tighten one bolt to 165 ft.-lbs. (watch the meter on the foot-pound wrench handle.) Then tighten the bolt on the opposite side of the cylinder head. Continue to tighten all of the opposite-side bolts until you have all the bolts tight. By tightening the bolts on alternating sides of the cylinder head, you will properly seal the head gasket in place.
