Where Is the Fuse Box in a 1999 Harley Davidson Fatboy?

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.
"The 1999 Harley-Davidson Fat Boy has a reliability rating of 67.8 (out of 100)."-- Bikez.com survey. 2011

Harley-Davidson began producing motorcycles in 1903. Their product lines include touring, street and cruising motorcycles. The 1999 Harley-Davidson Fat Boy is a cruiser designed for trips around town and adventures within 100 miles or so. The Fat Boy is considered reliable according to area Harley mechanics.

Expert Insight

The Fat Boy doesn't have common automotive fuses; it has circuit breakers. Fred Collins, Seminole Harley-Davidson speed and customization expert, explained: "The fuse/circuit breaker box on the 1999 H-D Fatboy houses four 15-amp circuit breakers and one 30-amp circuit breaker for the voltage regulator."


The fuse box on the 1999 Fat Boy, as with most motorcycles, is located under the seat to protect it from the elements and prevent water from entering. After removing the seat, the fuse box is visible behind the battery near the rear of the battery box.

Fun Fact

The five-speed 1999 Harley-Davidson Fat Boy has a 1,338-cubic-centimeter air-cooled engine -- yet only has a top speed of 94.4 mph. It can be attributed to the weight. The Fat Boy weighs a hefty 672.4 pounds, including engine fluids and 4.20 gallons of fuel.
