Troubleshooting Vermont Casting Radiance Fireplaces

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

Things You'll Need

  • Millivolt meter

  • Jumper wires

Image Credit: Comstock/Comstock/Getty Images

Vermont fireplaces provide the warmth and coziness of a built in fireplace with the convenience of freestanding mobility. If you experience a problem while using the Casting Radiance model, it may be easily fixed be performing a simple troubleshooting routine. If you do not find the source of your fireplace problems after troubleshooting, contact a Vermont technician for further assistance and to avoid damaging your fireplace permanently.

Advertisement

Igniter or Pilot Won’t Light or Stay Lit

Step 1

Make sure the gap by the pilot and the electrode connection is 1/8 inch wide.

Video of the Day

Step 2

Clean the pilot and adjust it so the flame will impinge on the thermocouple and the thermopile. These are the elements in the middle of the pilot circuit that cause the flame to ignite.

Advertisement

Step 3

Light the pilot with a match and then turn the pilot off. If the pilot lights, turn off the pilot and push the igniter button again.

Step 4

Replace the igniter if the pilot still won't light or if there are no sparks when you press the igniter.

Advertisement

Pilot Lights with No Gas to the Burner

Step 1

Check the connections of all of the wires between the pilot, burner and switches and ensure they are fitted tightly.

Step 2

Depress the valve knob in the "Pilot" position and take a reading of the thermopile with a millivolt meter. If the reading is any lower than 325 millivolts, replace the thermopile.

Advertisement

Step 3

Test the wires that connect to the remote or rocker switch with jumper wires. If the burner lights this way, replace the rocker switch.

Step 4

Check the wires at the valve of the pilot. If the burner lights this way the wires themselves are faulty and will require professional assessment.

Tip

Work in a well-lit area.

Warning

Keep flammable materials away from the fireplace when troubleshooting to prevent fires.
