How to Install Scuppers on a Self-Bailing Deck

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

Things You'll Need

  • Tape measure

  • Outside micrometer

  • Screwdrivers

  • Paint scraper

  • Scupper valve

  • End wrenches (if applicable)

  • Rags

  • Drill

  • Hole saw bit

  • Drill bits

If the bilge pump fails, a scupper valve is a last line of defense for flooding.

Scupper valves serve an important safety function on a boat. Comprised of a rubber flapper valve, or a ball check assembly, they allow the flow of water to travel in one direction at the deck location. Usually mounted in the stern, scupper valves allow excess water to drain off the deck and exit the transom, which avoids flooding the bilge and adding dangerous weight to the boat. Rain water, over-the-bow spray or leaking water is removed through the one-way valve. Any boat owner can install a first-time scupper valve or replace their old unit using a few basic tools and following some easy steps.

Step 1

Measure the deck height of your boat above the waterline with the fuel tanks full. If you normally carry several passengers on your outings, enlist some people to stand inside the boat, to simulate that load. If your deck height equals 4 inches or more above the waterline, you are safe to install a scupper or two just above the deck surface in the transom. If your height sits at or below the waterline, think about lightening your load or redistributing your passengers up toward the front when taking the boat out.

Step 2

Trailer your boat to a convenient work location. Locate the old scupper on your boat, if you need to replace it. Look for screws holding a circular flange, either on the inside or outside of the transom -- different brands vary with configuration. Remove the screws with a screwdriver. Use a paint scraper to pry the flange ring off -- be careful not to force it too hard. Pry evenly around the flange ring until it breaks free. Pull it off the transom.

Step 3

Pry the other end of the flange lip free and pull the drain tube assembly out. Use the paint scraper to shave off any old marine caulk or silicone on both sides of the transom. Remove the old caulk or silicone from inside the transom hole, making sure the bore is clean and smooth.

Step 4

Apply new silicone inside the transom bore hole and on the inside and outside of the transom, where the flange and flange lip will mount. Push a new scupper valve assembly into the hole until flush with the transom. Insert the inner (or outer) flange ring and reinsert the screws by hand in their mounting holes.

Step 5

Tighten the screws with a screwdriver. Note: some scupper valves will have through-bolt screws, so attach the nuts on the opposite side and hold them with an end wrench and tighten the screws. Wipe away excess marine silicone with a rag.

Step 6

Measure the thickness of your transom with an outside micrometer, from the top over the transom rail. Remember this measurement if you are installing a scupper valve for the first time on your boat. Purchase a scupper valve that has the same tube drain length dimensions as your transom thickness. Select a tube drain diameter of at least 1 inch or more, which will allow an adequate drain flow.

Step 7

Position yourself on the boat deck next to the transom, and pick a spot just above the deck to drill your drain tube hole. If installing two scupper valves, space them evenly apart from the outside rails. Fit the inside flange ring over your proposed location, to make sure it will fit without hitting the deck. Use a drill and a hole saw bit to drill the hole completely through the transom. Make sure the hole matches the outside diameter of the scupper drain tube.

Step 8

Apply marine silicone to the inside of the bore hole and to the inside and outside of the transom where the flanges will mount. Push the new scupper valve into the hole until it sits flush, taking care to set it with the arrow facing the rear of the boat, which shows the water flow direction. Place the inside, or outside, flange ring on the scupper valve, seating it flush. Use a drill and small 1/8-inch bit to drill the mounting screw holes through the flange ring, into the transom.

Step 9

Insert the mounting screws and tighten them evenly with a screwdriver. If the scupper valve has tube guides for a through-bolt design, drill through to the other side of the transom and install the nuts on the threads. Then, tighten the screws from the inside (or outside) with a screwdriver. Wipe away all excess silicone with a rag.

Tip

Some flange rings will mount either from outside of the transom or the inside. Obtain the exact scupper valve that has the same dimensions as your old one so that the mounting screw holes line up properly. If they do not line up, fill the old holes with marine silicone and drill new mounting holes.
